Anritsu Handheld Spectrum Analyzer MS2721A

The Anritsu Spectrum Master MS2721A was the first compact, fully-functional and handheld spectrum analyzer designed to conduct precise analysis on cellular signals and wireless LAN. This model`s most noticeable testing areas include: 802.11a, ultra-wideband, 3G, WiMAX, and Wireless Medical Patient Monitoring Networks. The MS2721A has a frequency range encompassing 100 kHz to 7.1 GHz.

With ≤–153 dBm Displayed Average Noise Level Typical @ 1 GHz, the kind of sensitivity this instrument offers is unprecedented in handheld spectrum analyzers that operate on batteries. Its higher sensitivity enables it to measure extremely low level and weak signals. The MS2721A comes with a broad range of resolution bandwidth options, thus you can configure your instrument to meet your specific measurement needs.

The Anritsu MS2721A is a suitable instrument for applications like RF and microwave signal measurements, cellular signal measurements, Wi-Fi / WiFi5 installation, and general spectrum monitoring. Its built-in demodulator for AM/FM/SSB can help you quickly catch interfering signals. The four sweep triggers it offers are: Free run, Single, Video, and External.

The MS2721A Handheld Spectrum Analyzer weighs approximately 6 lbs., therefore the user can easily take it everywhere including up to a tower. With remote tools, you will be able to control a MS2721A while sitting at your desk miles away from the device and see what is shown on the instrument`s screen. The model features eight languages, including Japanese and French. Two custom-defined languages can also be uploaded with the help of the software tools supplied.
