Fluke 317 Digital Clamp Meter

The 317 is an efficient digital clamp meter created by Fluke. This model delivers a comprehensive set of capabilities at an affordable price. The Fluke 317 clamp meter offers the 40 to 600A DC/AC current measurements with a high accuracy of 1.6 % and a resolution of 0.01 to 0.1 amperes. This enables the user to measure small currents with extreme precision. Other features on this model include: true RMS measurements, maximum and minimum values, and zeroing functionality. These features enable the user to smoothly conduct routine maintenance and installation work.

The Fluke 317 clamp meter offers the clamp opening of 37 mm, which enables the resistance measurement capability up to 4000 Ohms. The user can also carry out continuity testing for the resistance of fewer than 30 Ohms. The instrument incorporates a screen hold functionality. This allows the user to hold the measurement data on screen for specific requirements. It also has an advanced digital display, with a resolution of 6000 digits. The dimensions of the Fluke 317 clamp meter are 234 x 74 x 34.8 mm. The approximate weight of the instrument is 384 grams.

The Fluke 317 digital clamp meter comes with the IP rating of IP40. This model fulfills the drop test requirement for the maximum height of 1 m or 3 feet. It also comes equipped with various optional accessories, such as a TL223 SureGrip electronics testing package, an AC285 SureGrip alligator clips, and a L206 luxury LED cap lamp.
