Konica Minolta Chroma CL-200A Meter

Featured with a broad measuring range of 0.1 to 99,990 lx the CL-200A is a Chroma Meter from Konica Minolta. This meter is designed to measure illuminance, color temperature, excitation purity, chromaticity, XYZ Tristimulus values, and the dominant wavelength of different light sources. The Chroma CL-200A is an excellent tool for measuring white LED`s color temperature. It is a portable, compact, lightweight, and handheld model, which is ideal for simultaneous measurements. This model comes equipped with a silicon photocell and is designed to operate with an accuracy of + -2% + -1 digit.

The Chroma CL-200A weighs around 215g and can be powered through two AA-size batteries or an AC adaptor. This Chroma Meter features a USB interface as the computer interface. An RS-232C port is also provided to connect an external printer. For displaying results, it has a 4 significant-digit LCD. This model is offered with a specially designed data management software called CL-S10w. With this computer-based program, the user can transfer their data to Microsoft Excel® by utilizing body buttons.

The Chroma CL-200A comes with a detachable receptor head that can be disconnected and linked to the primary instrument through a standard LAN cable. This configuration ensures the installation of the sensor in an inspection system is a seamless process. This instrument is ergonomically designed since its dimensions are 69 x 174 x 35 mm and it can comfortably fit into the user’s palm. There is a low battery indicator provided to keep the user informed about the battery`s status.
