Keysight M9300A PXIe Frequency Reference

The M9300A is a PXIe Frequency Reference. The M9300A module is launched by Agilent/HP/Keysight Technologies. The M9300A is a part of the PXI Accessories Series. The M9300A can be installed on the 32-bit and 64-bit Windows 7 operating systems. The M9300A Frequency Reference can be used with a minimum available memory of 4 GB and 8 GB. However, a higher version of memory is recommended for the use of the M9300A. The standard compliant drivers and software for the Keysight M9300A are IVI-COM, IVI-C, LabVIEW, and MATLAB.

The M9300A PXIe Frequency Reference has multiple outputs for different functionalities. The M9300A has five 100 MHz reference outputs. The Keysight M9300A has one 10 MHz output and an internal 10 MHz OCXO time-base output. The M9300A can also be used as a source output. The Keysight M9300A PXIe Frequency Reference additionally works as a modulator to build an advanced vector signal generator. The M9300A is a PXIe modular device that is used as a reference of 10 MHz or 100 MHz in various solutions.

The M9300A PXIe Frequency Reference has vast uses in the wireless communications, aerospace, and defense systems applications. The M9300A supports reducible development time. The Keysight M9300A PXIe Frequency Reference offers a simple way of integration towards the available test environments with various drivers, as well as programmatic interfaces. The M9300A reduces start-up time with the Keysight IO libraries. The M9300A PXIe Frequency Reference comes with a soft front panel. The M9300A has 1 PXIe slot, low phase noise, and a 100 MHz output amplitude ≥ 10 dBm.
