Keysight 82350C High Performance PCI-GPIB Interface Card

The 82350C is an efficient PCI-GPIB Interface Card. This high-performance card is manufactured by Agilent/HP/Keysight. The Keysight 82350C is an IEE 488 PCI interface designed for PCs. The 82350C offers a maximum data transfer rate of 900 KB/s. The Keysight 82350C also provides support of dual processors on the latest Windows OS (operating systems). The Keysight 82350C PCI-GPIB Interface Card has a flexible connection feature through low profile and standard brackets. The 82350C can be used with a quick start placard. The Keysight 82350C also provides plug and play configuration, as well as built-in buffering.

The Keysight 82350C PCI-GPIB Interface Card requires Backplane +3.3 V or +5 V PCI for power. The 82350C has IEEE 488, 24 pins (GPIB), and Universal +3.3 V and +5 V PCI connectors. The Keysight 82350C can support a maximum of 14 instrument connections at a time. The 82350C PCI-GPIB Interface Card offers two PCI bus slots. One slot is +5 V PCI (32 bit) and the second slot is universal +3.3 V (32 bit).

The Keysight 82350C PCI-GPIB Interface Card displays high performance in test applications for manufacturing or automation applications. The Keysight 82350C is completely compatible with the communication and control standards of IEE 488. The 82350C High Performance PCI-GPIB Interface Card can be operated in - 5 °C to +60 °C temperature range. The Keysight 82350C card allows flexible plugging options with a simple bracket change for low profile or standard PCs.
