National Instruments NI-9252 C Series Voltage Input Module

The NI-9252 is a Voltage Input Module for the C Series. The NI-9252 is developed by National Instruments. National Instruments has launched the module under two part numbers: 786782-01 and 786783-01. The NI 9252 is released with the product family of the C Series Voltage Input Modules by National Instruments. The NI-9252 Voltage Input Module contains 8 differential analog input channels. The input voltage range of the NI-9252 module is ±10 V.

The NI-9252 C Series Voltage Input Module is capable of performing simultaneous sampling with a sampling rate up to 25 kS/s. The NI 9252 module works with the resolution of 24 bits for the analog inputs. The NI-9252 module is built with either screw terminal or D-SUB connections on the front panel. The NI-9252 module features multiple programmable filters. The NI-9252 module can function with ground isolation of 250 Vrms. The National Instruments NI-9252 C Series Voltage Input Module is manufactured as an enclosed module.

The NI-9252 C Series Voltage Input Module is designed for use with the Compact reconfigurable input/output (CompactRIO) systems. The NI-9252 module is compatible with the hardware systems of Compact data acquisition (CompactDAQ) devices as well. The NI-9252 module is included in the CAT I type of standard modules. The NI-9252 module is operated with an input delay tolerance of ±100 ns. The internal noise of the system can be reduced by using the NI-9252 module comb and Butterworth filters. The NI-9252 module is accredited with an ingress protection of IP40.
