National Instruments cDAQ-9137 CompactDAQ Controller

The cDAQ-9137 (Part numbers: 784240-01 and 784241-01) is a data acquisition Controller by National Instruments. This model is equipped with a 1.91 GHz Quad-Core Atom Processor. This model has 32 GB nonvolatile storage. The NI cDAQ-9137 is structured with four general purpose counters/timers with a resolution of 16-bits. The device is also equipped with two Gigabit Ethernet ports and two USB ports, as well as an RS232 serial port and a mini display port. Moreover, this model has an SMB trigger line, an SD slot, and USB device configuration. The device is capable to run seven hardware timed analog and digital terminals concurrently. It can also operate counter/timer operations instantaneously.

The NI cDAQ-9137 has one channel to generate frequency. The frequency generator has 16 divisors with a base clock precision of 50 ppm. The module has multiple data stream types available, including AI, AO, and NI -XNET. It also includes digital input, digital output, counter/timer input, and counter/timer output. The NI cDAQ-9137 has 3.4 W standby power usage at 24 VDC input. The NI cDAQ 9137 can interface with C Series modules.

The operating humidity is from 10 to 90% RH and the storage humidity is from 5%to 95% RH. The NI cDAQ-9137 has the random operating vibration of about 5 grms and an operating shock value of 30 g. The device justifies the EMC necessities for electrical equipment. These standards are essential for control, measurement, and lab use.  This model also has a hazardous locations certification.
