National Instruments cDAQ-9185 CompactDAQ Chassis

The cDAQ-9185 (Part Numbers: 785064-01, 786473-01, 787929-01) is a CompactDAQ Chassis. With this model, the user can introduce a thermocouple module by an accelerometer estimation module and gain both at various rates. The NI cDAQ-9185 Chassis has numerous simple information timing motors, which allows the user to gather the majority of their simple info modules in up to three arrangements of modules. These sets, known as undertakings, would all be able to keep running at various rates if each has its own specific motor planning in the backplane undercarriage. This reduces the need to demolish bring down speed information from the higher-speed information.

To exploit the 1,000 Mbit/s of data transmission on a Gigabit Ethernet interface, this NI CompactDAQ Chassis actualizes a TCP/IP variant of the same protected NI Signal Spilling innovation on elite NI USB data acquisition items. With this innovation, fast C Series modules, such as the NI 9223, can persistently gain up to 1 MS/s of synchronous 16-bit information on all four channels. Besides, various NI CompactDAQ undercarriages can have a similar Gigabit Ethernet organized for appropriated, high-channel-count frameworks. The device has a timing accuracy of 50 ppm of sample rate.

Utilizing a modern programming design, NI-DAQmx driver programming keeps up a twofold cradled exchange component between the frame and host PC equipped for maintaining a few bidirectional constant waveforms. In the meantime, the driver screens the condition of the system to modify for startling deferrals or transitory intrusions. The greater part of this is preoccupied from the client, so the user can center on the estimation application and not the system. The device can be programmed using LabVIEW or LabWindows/CVI.

The NI device weighs 23.3 oz, and measures 7.01 x 3.47 x 2.52 in. in physical dimensions. It has a recommended operating temperature range of -40 °C to 70 °C, a storage temperature range of -40 °C to 85 °C, non-condensing operating and storage humidity ranges of 10% to 90% RH and 5% to 95% RH respectively, and random and sinusoidal operating vibrations of 5 grms and 5 g respectively–all at a frequency range of 10 to 500 Hz. More information about the cDAQ-9185 can be found in the datasheets and manuals of the "Manuals & PDFs" tab.

The cDAQ-9185 is available to be calibrated. While the recommended calibration period for individual parts varies, most parts should be calibrated either annually or every two years to ensure accuracy. If you need the cDAQ-9185 calibrated, Apex Waves provides options. We offer high-quality NIST accredited calibrations through a 3rd party, with an average turnaround time of 1 to 2 weeks. When you order the cDAQ-9185 with us, you can request basic (unaccredited) in-house calibration that will calibrate the part to the manufacturer specifications prior to being shipped. Call or email us today for more information about calibrating the cDAQ-9185!
