National Instruments cRIO-9112 CompactRIO Chassis

The cRIO‑9112 (Part Number: 780916-01) is an entire reconfigurable implanted framework for tough solitary or organized control and obtaining applications. The reconfigurable inserted framework is comprised of a continuous controller, a reconfigurable body containing the user programmable RIO FPGA, and an assortment of hot-swappable mechanical I/O modules. In this design, a CompactRIO extension case associates with the advanced port on an FPGA gadget. The gadget can be introduced in any work area PC, modern PC (IPC), or ruggedized PXI/CompactPCI PC framework running Windows or one of the LabVIEW Real-Time OS software types. The RIO FPGA dwells on the gadget, while the cRIO 9112 changes over a computerized port on the gadget into an elite development I/O and flag molding framework. The device has an embedded RAM of 1,152 kbits.

Notwithstanding automatic correspondence by means of TCP/IP, UDP, Modbus/TCP, IrDA, and serial conventions, the CompactRIO controllers additionally incorporate inherent servers for VISA, HTTP, and FTP. The VISA server gives remote download and correspondence access to the RIO FPGA over Ethernet. The HTTP server offers a Web program UI to HTML pages, documents, and the UI of implanted LabVIEW applications through a Web program module. The FTP server gives access to logged information or setup documents. The cRIO-9112 has a power consumption of up to 500 mW at +5 VDC, and 2100 mW maximum at +3.3 VDC.

I/O modules give the interface between bundle pins and the inward configurable rationale. Most well-known and driving edge I/O measures are bolstered by programmable I/O squares (IOBs). The IOBs can be associated with exceptionally adaptable ChipSync logic for upgraded source-synchronous interfacing. Source-synchronous improvements incorporate per-bit deskew (on both information and output signals), information serializers/deserializers, clock dividers, and devoted I/O and neighborhood timing assets.

The cRIO-9112 weighs 31 oz. It has recommended operating and storage temperature ranges of -40 °C to 70 °C and -40 °C to 85 °C respectively, non-condensing operating and storage humidity ranges of 10% RH to 90% RH and 5% RH to 95% RH respectively, random and sinusoidal operating vibrations of 5 grms and 5 g–all at a frequency range of 10 to 500 Hz.
