National Instruments CVS-1457RT Compact Vision System

Featured with an Intel Atom processor and TTL digital I/O capabilities, the NI CVS-1457RT is a Compact Vision System from National Instruments. This system comes with PoE (Power over Ethernet technology) and can help you deploy your visual systems simply with less cabling. The CVS-1457RT has network connectivity and can easily be considered for various machine vision applications.

The TTL digital I/O lines provided on this Compact Vision System are backed by an integrated FPGA. This real-time imaging system is designed to acquire, process, and display images directly from GigE Vision compatible cameras. The NI CVS-1457RT also offers a variety of digital I/O options. These I/O options enable users to utilize a broad range of external devices to configure and initiate an inspection and to compile and display results. The front panel of this device has 1 VGA connector, 1 RJ50 serial port, 2 USB 2.0 ports, 1 Ethernet connector, and 2 PoE compatible GigE ports. For digital communications with external devices, this model has a 44-pin digital I/O port as well.

The digital I/O port comes with 8 isolated inputs, 2 bidirectional differential pairs, 8 isolated outputs, and 8 bidirectional TTL lines. The NI CVS-1457RT features a user-configurable FPGA that permits the digital I/O to be customized and configured for specific applications. The two PoE enabled ports are capable of providing data and power connection to GigE Vision compatible cameras.

CVS-14757 Mature Status has been announced by National Instruments, but the Compact Vision System will still be available for purchase and repairs by Apex Waves.
