National Instruments DAQCard-6533 Digital I/O Device

The DAQCard-6533 is a Digital I/O Device manufactured by National Instruments. The NI DAQCard-6533 is available to order with the part number 777315-01. The DAQCard-6533 is a member of the NI-6533 family. The DAQCard-6533 is programmed with the NI-DAQ driver software. This driver software helps make configuring the device easier. The DAQCard-6533 can be worked on LabVIEW, LabWindows, and Measurement Studio. The DAQCard-6533 can be installed on Windows, Real-time performance with LabVIEW, and Mac OS X operating systems. The NI DAQCard-6533 is compatible with different versions of Windows, including Windows 2000/XP/NT. The DAQCard-6533 can also function with other types of software such as Visual Basic, C, and C++.

The DAQCard-6533 is modeled to provide high performance for digital input/output plug-in modules. This Digital I/O Device is built for use with PCMCIA slots. The maximum transfer rate for the NI DAQCard-6533 is available as 20 MHz with 80 MB/s. The DAQCard-6533 is designed as a high-speed digital I/O device for handshaking interface purposes. This device has 32 digital I/O lines with the compatibility of the TTL/CMOS standard and 5 V as a voltage source.

This Digital I/O Device has a 16-sample FIFO memory size. The power consumption at the input/output connector is available as +4.65 to +5.25 VDC voltage at 250 mA current with a PCMCIA port. The DAQCard-6533 can start and stop triggering operations and can transform the detection pattern. The DAQCard-6533 requires a current of 500 mA. This device also has 10 ns minimum pulse width for edge triggers and 500 mV hysteresis.
