National Instruments FP-PS-4 FieldPoint Power Supply Module

The NI FP-PS-4 (Part Number: 778586-90) is a Power Supply Module by National Instruments. National Instruments offers five DC Power Supplies for FieldPoint frameworks. The user can interface the power supply output to the FP-PS-4, which directs, channels, and conveys capacity to the bank of as many as eight I/O modules that it controls. The NI FP-PS-4 Power Supply Module has a basic rail cut for dependable mounting onto a standard 35 mm DIN rail. Pursue these means to mount the module on a DIN rail. The FP-PS-4 gives a 24 VDC output. The user chooses the quantity of National Instruments FP-PS-4 Power Supplies they need in their bank, dependent on the power and segregation necessities. The aggregate intensity of the majority of the FieldPoint modules and different gadgets associated with a FP-PS-4 cannot surpass the predetermined output for the temperature run at which the user is utilizing the FP-PS-4 module.

The NI FP-PS-4 can store one pending direction for each channel. The Control: Stop Immediately makes impact when the direction is received. The Control: Stop After Current Pulse activity and the Generate Pulses direction are conceded until the finish of the current heartbeat if a heartbeat train is being produced. When a direction is pending and a second order is received, the pending order is disposed of and the new order is executed. Utilize a 16 to 26 AWG stranded wire to interface the National Instruments FP-PS-4 to a FieldPoint module or I/O module. Interface the positive wire to the V terminal and the negative wire to the C terminal of the FP-PS-4.
