National Instruments NI-5792 RF Adapter Module for FlexRIO

The National Instruments NI-5792 (Part Number: 782511-01) RF Adapter Module for FlexRIO gives a nonstop frequency range from 200 MHz to 4.4 GHz. This module includes a single stage, coordinate change engineering that gives high transmission capacity in the little frame factor of a FlexRIO connector module. The installed synthesizer, which is the local oscillator (LO), sets the inside frequency for procurement and generation. The user can send out it to different modules for Multi Input, Multi Output (MIMO) synchronization. Users can also import the LO from an outer connector, empowering synchronization of as many as eight NI-5792 modules.

The direct access to raw ADC and DAC information on the NI-5792 FlexRIO RF Adapter Module gives a definitive adaptability in advanced signal processing, information storage and streaming, and custom calculation plan for software defined radio (SDR), signal insight (SIGINT), storage to and from circle, MIMO, beamforming, and other elite inner RF applications.

The NI-5792 comes with a CLIP function that produces one sample for every time cycle at a default test rate of 250 MHz. Users can set a lower test rate by utilizing an outside Sample Clock. This CLIP gives access to I and Q information for one RF receiving channel. The CLIP additionally gives a User Command interface to normal setups of the base-band timing, programmable attenuators, receive amplifier, get channels, LO channels, and RF way which incorporates the capacity to import and fare the LO. The baseband timing can be designed utilizing settings like Internal Sample Clock, Internal Sample Clock to an outside Reference Clock through the CLK IN connector, and internal Sample Clock.
