National Instruments PCI-8366 Device for PXI Remote Control

The PCI‑8366 (Part Number: 781400-01) Remote Controller gives a PCI interface over a fiber-optic link to the PXI‑8368 remote control module when utilized for PXI framework control. Fiber-optic remote control arrangements are perfect for long‑distance‑device control and electrical detachment. NI framework checking programs are intended to make it much less demanding for users to possess a NI framework. These projects incorporate designing and sending administrations for NI PXI, CompactRIO, or Compact FieldPoint frameworks. The NI Basic System Assurance Program gives a straightforward mix test and guarantees that the user’s framework is conveyed totally collected in one box. With the NI PCI-8366 Device for PXI Remote Control, the user can control PXI Express and CompactPCI Express frameworks from a PCI Express-prepared work area or a server PC through a completely straightforward, high-data transfer capacity cabled MXI-Express connection. The NI PCI-8366 device is comprised of a PCI Express board in the PC, associated by means of an MXI-Express link to a PXI Express module in space 1 of a PXI Express suspension.

The PCI-8366 device offers direct PC control of PXI by means of a PCI opening, a software-straightforward connection that requires no programming, up to 200 m with fiber-optic cabling, 100 MB/s rates, and one MXI port. This model has dimensions of 2.48 x 4.76 inches and weighs 0.15 lb. typical.  The NI PCI-8366 is also compatible with the PCI Specification, Revision 3.0. This model requires one PCI slot, which can be either regular height or low profile.
