National Instruments DB37F-PIGTAIL Multifunction Shielded Cable

The DB37F-PIGTAIL Multifunction Shielded Cable (Part Number: 193737-01, 778620-04, 188843-01) is specially engineered for applications with high electronic noise. The DB37F-PIGTAIL Multifunction Shielded Cable is an I/O cable, 1 meter in length, and is meant for use with NI boards with 10 Digital I/O, 4 Analog Inputs, and 4 Analog Outputs.  The DB37M-DB37F-EP caters specifically to high voltage and high ambient noise applications.

The DB37M-DB37F-EP Multifunction Shielded Cable possesses a 37-pin standard female D-Sub connector on one end and a standard 37-pin D-Sub male connector on the other end. The National Instrument DB37M-DB37F-EP cable is compatible with a number of National Instruments modules. The DB37M-DB37F-EP is compatible with the NI-6230 and NI-6236 modules and the NI 92-, 93-, and 9400 modules with 37 pins. The shielding of the DB37F-PIGTAIL Multifunction Shielded Cable allows for optimal operations.

The DB37F-PIGTAIL Multifunction Shielded Cable belongs to National Instrument’s extended performance cables collection and boasts higher performance and EMI shielding. The DB37F-PIGTAIL’s pairing is twisted to enable efficient rejection of environmental noise. The DB37F-PIGTAIL cable connects to terminal blocks, wires, NI and third-party accessories, and DAQ modules and devices. Suitability of the DB37F-PIGTAIL Multifunction Shielded Cable for an application depends upon connector types, hardware requirements, and environmental conditions. As the DB37F-PIGTAIL Multifunction Shielded Cable is internally twisted and shielded, it is suitable for applications with high ambient noise and requiring high-performance. The DB37F-PIGTAIL has front- and back-end connectors to enable easy connection in the field.

The DB37F-PIGTAIL Multifunction Shielded Cable is a D-SUB connection cable with 37 pins on both the male and females ends. The shielding and internal twisting of the DB37F-PIGTAIL improves performance, reliability, capability, and versatility. The DB37F-PIGTAIL Multifunction Shielded Cable should be used to applications utilizing a compatible NI module, running high voltage, and experiencing high ambient noise.
