National Instruments PXIe-4310 PXI Analog Input Module

The PXIe-4310 (Part Number: 784813-01) is an advanced Analog Input Module from National Instruments with 8 Analog Input Channels. The NI PXIe-4310 module offers a maximum sample rate up to 400ks/s per channel. This module can create four different input ranges, which enables the PXIe 4310 to trigger configurations simultaneously at the output. The PXIe-4310 Analog Input Module also has the ability to choose an analog filter per channel. It improves the performance and measurement accuracy of the module.

The NI PXIe-4310 is structured with eight simultaneously sampled analog input channels. All these channels have channel-to-earth and channel-to-channel isolation. The maximum Analog Input Isolation is ranged up to 600 V channel to channel. A driver NI-DAQmx can be used for measurement and simplifies hardware configuration. The range of the PXIe-4310 can be enhanced up to 10 V maximum with the assistance of TB-4310 (10V).  It can be further expanded to 600 V with the assistance of TB-4310 (600V). Triggering/clocking is executed by using two inputs PFI lines. One of the key features of the NI PXIe-4310 Analog Input Module is self-calibration, which measures the onboard reference voltage of the module and prevents any errors caused by short-term fluctuations in the environment.

The National Instruments PXIe-4310 PXI Analog Input Module's dimensions are 6.3 x 3.9 inches. The instrument weighs 6.0 oz. The power requirement of the device is +3.3 volts at 2.9 watts and +12 volts at 7.1 Watts. The NI PXIe-4310 Analog Input Module also complies to industrial safety standards.
