National Instruments PXIe-8880 PXI Controller

The NI PXIe-8880 (Part Numbers: 783513-05, 783513-04, 783513-33 and 154471B-01L ) is an 8-Core PXI Controller, with an SMB connector on the front board that can be associated with or from any PXI Express line initiation of the backplane. An actuation task process is expected to keep two assets from associating with a similar enactment line, which makes the trigger activate twofold and perhaps harm the equipment.

The PXIe 8880 Controller offers 24 GB/s of system bandwidth and 8 GB/s slot bandwidth, 8 GB (1 x 8 GB DIMM), triple channel 1866 MHz DDR4 RAM standard, and 2.3 GHz with an eight-core Intel Xeon E5-2618L v3 processor. The device is equipped with 1 system slot and 3 controller expansion slots.

To redesign the RAM, expel the NI PXIe-8880 from the PXI Express chassis. To enhance memory limit and framework execution, utilize a similar size and speed memory modules. The utilization of various size modules in each space is bolstered, however framework execution will be slower than utilizing three coordinated modules. In any case, three mismatched modules could result in better execution over utilizing a single module.

This inserted PXI Express controller is the true decision for elite, high-throughput, and computationally serious test and estimation applications, for example, 5G cellular inquire research, semiconductor creation test, and RF record and playback and in addition any application for which test time and time to showcase are critical. The NI device operates using the NI-DAQmx, NI-VISA, NI Modular Instruments, and NI-Industrial Communications for EtherCAT driver software which are compatible with software packages/application development environments (ADEs) such as LabVIEW. LabWindows/CVI, Measurement Studio, Microsoft Visual Basic, Visual Studio .NET, or Visual C++.

Considering the CPU's multicore nature, this installed controller is especially valuable when combined with framework plan programming that is improved for parallel processing, such as LabVIEW and TestStand. The four-wide 3U PXI Express module weighs 3.4 lbs. It has a recommended operating temperature range of 0 to 50 °C, and a storage temperature range of -40 to 71 °C. The device has a DisplayPort, 2 RJ45, 1 USB 4-pin series A stacked receptacle, 1 USB 9-pin series A stacked receptacle, a SMB, and a 25-pin Micro D connector.
