National Instruments PXIe-5820 PXI Vector Signal Transceiver

The PXIe-5820 (Part Number: 783967-01) is a 2-Slot Vector Signal Transceiver from National Instruments, which incorporates extraordinary operational capabilities. The NI PXIe-5820 offers the frequency bandwidth of 1 GHz. This frequency spectrum is of I/Q type and extremely complex. The modul integrates various advanced capabilities, including a wideband I/Q digitizer and wideband I/Q arbitrary waveform generator. It also includes a high-performance FPGA module, which is user programmable. Each of these functionalities are combined on a single PXI Express module.

The National Instruuments PXIe-5820 Vector Signal Transceiver has an exceptional tuning time for the built-in generators. Their typical tuning time is approximately 0.38 milliseconds. The instrument also incorporates onboard dynamic RAM, which includes 2 banks of the DRAM. Each bank has the memory size of 2 GB per second. The theoretical maximum data rate of each bank is 12 GB per second per bank. This Vector Signal Transceiver has an onboard static RAM memory size of 2 MB. The maximum data reading rate is 31 MB per second and the maximum data writing rate is 29 MB per second.

The NI PXIe-5820 Vector Signal Transceiver comes with DC and per terminal input coupling. The input type for the instrument is differential. It also incorporates two channels for the input. This model also has a DC differential input impedance with a typical value of 100 ± 10 Ohms. It has the dimensions of 1.6 x 5.1 x 8.5 inches. The NI PXIe-5820 weighs 1.8 lb.
