National Instruments PCIe-7857R Multifunction Reconfigurable I/O Device

The PCIe-7857R is a Multifunction Reconfigurable I/O Device. The PCIe-7857R device is developed by National Instruments. The NI PCIe-7857R is a member of the R Series offered by NI. The PCIe-7857R is released with the part number 786458-01. The PCIe-7857R is used for multifunction purposes. The NI PCIe-7857R can be customized using the LabVIEW FPGA Module for multiple applications.

The NI PCIe-7857R Multifunction Reconfigurable I/O Device has been assembled with a reconfigurable FPGA. The FPGA is a Kintex-7 160T FPGA that features 11,700 kbits of embedded block RAM. The PCIe-7857R Multifunction Reconfigurable I/O Device features a dedicated ADC for every channel to provide independent timing and triggering facilities. The PCIe-7857R offers an additional advanced feature of multirate sampling.

The National Instruments PCIe-7857R Multifunction Reconfigurable I/O Device has been designed with 8 analog input and 8 output channels. The NI PCIe-7857R is prepared to control input/output signals. The PCIe-7857R has 48 bidirectional digital input/output channels with 1 MS/s maximum channel sampling rate. The PCIe-7857R Multifunction Reconfigurable I/O Device is fabricated with 512 MB of DRAM memory. The NI PCIe-7857R is used with PCI Express x4, x8, and x16 bus connectors. The PCIe-7857R Multifunction Reconfigurable I/O Device is offered with a slew rate of 10 V/us. The PCIe-7857R comes with two 68-pin VHDCI input/output connectors. This device has a maximum clock rate of 80 MHz. The NI PCIe-7857R is similar to the PCIe-7856R, but the PCIe-7857R is an enclosed device.
