National Instruments SCXI-1333 Terminal Block

The SCXI-1333 (Part Number: 777687-33) is a universally useful terminal block that gives the user access to all row and column connections. Because of the general-purpose nature of this terminal piece, the user can join the row or columns to make a wide range of network configurations. Spring terminals on the SCXI-1333 enable the user to get to every 4 × 16 framework. The SCXI-1333 gives terminals to scanner advanced output and outer input trigger signals and contains two 128-pin DIN connectors for connecting columns between modules. This module is rated for Measurement Category I and planned to offer signal voltages no more noteworthy than 150 V. This module can withstand up to 800 V impulse voltage. The user should try not to utilize this module for connection with signals or for estimations inside Categories II, III, or IV and try not to interface with MAINS supply circuits (for instance, wallet outlets) of 115 or 230 VAC.

When utilizing network development plugs, just interface terminal blocks of the same type. Interfacing diverse sorts of terminal block can harm the module or the hardware associated with the module. For instance, the user can interface at least two SCXI-1333 terminal blocks.

The most effective method to utilize a matrix extension plug with SCXI terminal blocks is to expand the quantity of lines of a 4 × 32 matrix. The matrix extension plug interfaces columns to extend the quantity of rows. To extend the quantity of rows of a matrix, associate a matrix expansion plug to the top or base column connectors of the two terminal blocks.
