SCXI-1502 Technical Specifications:
| Manufacturer | National Instruments |
|---|---|
| Model | SCXI-1502 |
| Part Number | 779514-01 |
| Series | SCXI Series |
| Type | High Performance Thermocouple Module |
| Repair Evaluation | $150 |
SCXI-1502
Home SCXI-1502
| Part Number | SCXI-1502 |
| Manufacturer/Brand | National Instruments |
| Description | SCXI-1502, 32-Channel, High Performance Thermocouple Module |
Speak to a sales representative for pricing & lead time:
Phone:1-919-809-5227
• Quick Quotes: Receive Price & Availability Today!
• Warranty: 1 Year Warranty Covered by Apex Waves
• Calibration: Ask About Our Tiered Calibration Levels
• Option & Modules: Confirm Your Requirements or Versions
• Repair: Cost & Lead Time Available Upon Request for Service
- Description
- Technical Specifications
- FAQ
National Instruments SCXI-1502 High Performance Thermocouple Module
The NI SCXI-1502 (Part Number: 779514-01) is a member of the SCXI Series by National Instruments. This High Performance Thermocouple Module has 32 channels. The SCXI 1502 module can be used with the following operating systems: Windows 7/Vista x64, Windows 7/Vista x86, Windows XP, Windows 2000, LabVIEW Real-Time Phar Lap, and Linux. For these operating systems, the module will work with NI-DAQmx 8.1. This module is not supported by Windows NT or Max OS X.
The National Instruments SCXI-1502 High Performance Thermocouple Module has 32 pins on the front panel. In column A, there are several descriptions for the pins. NC means no connection and RSVD means reserved. The channels are numbered beginning at CH 0 -, then CH 1 –, etc. for column B. Column C starts at CH 0 +, then CH 1 +, etc. For reference, the pin-out can be found in the user manual.
The NI SCXI 1502 module has the capability to be externally calibrated. However, calibration services can no longer be obtained at NI.
SCXI-1502 Obsolete Status has been announced by National Instruments, but the module will still be available for purchase and repairs by Apex Waves.
| Model | SCXI-1502 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 779514-01 |
| Type | High Performance Thermocouple Module |
| Channels | 32 |
| Driver | NI-DAQmx 8.1 |
| Warranty | 2-3 Year Warranty |
| SCXI-1502 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
