National Instruments PXI-8432/2 PXI Serial Interface Module

The 2-Port, Isolated, RS232 Serial Interface Module PXI-8432/2 (Part Number: 779744-01, 191050C-01L) is a superior interface for rapid port-to-port isolated communication with RS-232 gadgets. It has elite, multi-threaded DMA transfers and multiprocessor support. NI Serial Interfaces additionally appear as standard COM ports for compatibility with programs that use serial communications.

The NI PXI-8432/2 high-execution serial interfaces deliver many highlights, such as adaptable baud rates up to 2 Mb/s, and hyper threading and multiprocessor similarity. With the adaptable baud rate abilities of the NI PXI-8432/2 Serial Interface Module, the user can communicate with gadgets that work with nonstandard baud rates running from 57 b/w up to 2 Mb/s inside 1 percent and standard baud rates inside 0.01 percent. With multiprocessor and hyper threading similarity, the user can additionally take advantage of the most recent PC innovation for higher speeds and enhanced productivity. The new programming driver included with the gadget offers better asset designation and DMA access for higher throughput with CPU use. Moreover, the PXI-8432/2 interface incorporates new memory-mapping highlights that can be used to associate with more serial gadgets without resource conflicts. The NI PXI-8432/2 interface is a universal board, completely compatible with both 5 and 3.3 V signaling conditions so the board can work in an extensive variety of PCs.

Apex Waves will continue to Buy, Sell, and Repair EOL NI Hardware in perpetuity. While the PXI-8432/2 entered the NI Maintenance phase on March 31, 2023, it will remain available with Apex Waves. Request your quote today!
