National Instruments VB-8012 VirtualBench All-in-One Instrument

Featured with a programmable power supply (DC), an arbitrary waveform generator, and other instruments, the NI VB-8012 (Part Numbers: 783555-05, 783555-02, 783555-11, 783555-04, 783555-12, and 783555-01) is a 100 MHz bandwidth, 2-Channel VirtualBench All-in-One Instrument. This instrument comes with a specially designed software program that allows you to view your measurements interactively. The NI VB-8012 offers protocol analysis through its 100 MHz, two-channel oscilloscope. This instrument has an integrated digital multimeter as well.

This VirtualBench All-in-One Instrument is designed to provide you with a variety of measurement and analysis tools in a single package. Thus, you can save a lot of money and time that otherwise will be required for the acquisition and configuration of several devices. The oscilloscope incorporated in the National Instruments VB-8012 VirtualBench All-in-One Instrument has a resolution of 8-bits and supports both AC and DC coupling. This instrument features a 34-channel digital logic analyzer as well. The waveform function generation incorporated in the NI VB-8012 can generate arbitrarily, sine, square, ramp/triangle, and DC waveforms with an update rate of 125 MS/s and 14-bits resolution.

The VB-8012 VirtualBench All-in-One Instrument not only provides you with five essential tests and measurement devices but is capable of integrating with your personal computer as well. Thus, you can easily import your measurements and other data from this device to your computer. The programmable DC power supply incorporated in the NI VB-8012 has three channels. Each channel has a different range of voltage/current. The digital multimeter has a wide range of measurement functions including: AC voltage, DC voltage, DC current, AC current, resistance, etc.
