National Instruments VXI-AO-48XDC DC Setpoint Module

The VX-AO-48XDC (Part Number: 777417-01) is a DC Setpoint Module. The NI VXI-AO-48XDC is designed by National Instruments. The VXI-AO-48XDC is a module for VXI bus that converts the VXI bus system into a digital I/O system for different types of testing, including equipment testing, protection testing, laboratory equipment testing, and industrial process monitoring.

The VXI-AO-48XDC has 48 voltage and current input channels and 32 digital I/O lines, which can be used in various DC setpoint and digital applications. The VXI-AO-48XDC module is widely used in experimental stimulated signaling, generating analog functions, and interfacing with electromechanical relays, LEDs, optical isolations, solid state relays, and I/O modules. The VXI-AO-48XDC is highly compatible with software like LabVIEW, ComponentWorks, NI-VISA, VirtualBench, LabWindows, and NI-DAQ. ComponentWorks is a high-level programming interface software for providing virtual instruments through OLE and DLLs and provide resource management utilities, as well as interactive control utilities with this DC Setpoint Module. LabVIEW is a user-friendly interactive software platform for the VXI-AO-48XDC with powerful graphical programming. LabWindows has a state-of-the-art user interface and ANSI-standard C programming language is widely used language in this software.

National Instruments offers various compatible accessories for the VXI-AO-48XDC module, including cables with cable assemblies and connector blocks. Custom cabling can also be designed by the user, enabling you to have a wide range of test instruments interface, I/O modules with racks, and any parallel interface device. The digital I/O connector of the VXI-AO-48XDC is a standard 96-pin DIN header connector.

VXI-AO-48XDC Obsolete Status has been announced by National Instruments, but the module will still be available for purchase and repairs by Apex Waves.
