National Instruments PXIe-6365 PXI Multifunction I/O Module

The PXIe-6365 (Part Number: 783633-01) is an advanced Multifunction I/O Module from National Instruments with 72 differential analog input channels. The NI PXIe-6365 module can also offer 144 single-ended channels. This module has a built-in ADC with the resolution of 16 bits. There are different sample rates available for different modes of operation, such as 2 MS per second for a single channel and 1 MS per second for the multichannel mode of operation. The NI PXIe-6365 Multifunction I/O Module also implements DC input coupling. The NI PXIe-6365 Module weighs around 203 grams.

The NI PXIe-6365 module has a CMRR value of 100 dB. The instrument exhibits amazing static characteristics. It comes with 24 static channels. The user can program each terminal. This module offers the flexibility to program each terminal as either an input or output. It also includes a ground reference. The typical value for pull-down resistance is 50 kilo-ohms. The NI PXIe-6365 Multifunction I/O Module has an input voltage protection scheme for the voltage range of ± 20 volts, up to two pins.

The NI PXIe-6365 Multifunction I/O Module has a decent FIFO memory with the capability to store as many as 255 samples. The size for the output FIFO, on the other hand, is 2047 samples. It comes with the resolution of 32 bits. The instrument also offers a port or sample size of 8 bits for waveform generation. It makes use of port 0 for the generation of waves.
