Spirent SmartBits LAN-3150A Ethernet RMII/SMII Module

The SmartBits LAN-3150A is a high-quality Ethernet Module. Spirent Communications designs the SmartBits LAN-3150A Ethernet Module. The SmartBits LAN-3150A module is compatible with the RMII and SMII genre of DUTs. The operation of the Spirent SmartBits LAN-3150A Ethernet Module is compatible with the SmartBits SMB-600 or SMB-6000B Performance Analysis Systems. The functional compatibility of the SmartBits LAN-3150A Ethernet Module is with the SmartBits LAN-3100A module. The key features of the Spirent SmartBits LAN-3150A module are ARPing, VLAN tagging, and IP checksum generation.

The SmartBits LAN-3150A RMII/SMII Ethernet Module features 8 ports of 10/100 Mbps speed, which can be configured either as full or half-duplex Ethernet ports. The SmartBits LAN-3150A Ethernet Module by Spirent Communications features a selectable operational mode for user-dependent RMII or SMII and uses a common clock reference for establishing the connection with both genres of DUTs. The SMII synchronization of the Spirent SmartBits LAN-3150A module is done through a global 12.5 MHz pulse. The frame size featured by the Spirent SmartBits LAN-3150A RMII/SMII Ethernet Module is 20 – 2048 bytes.

The SmartBits LAN-3150A RMII/SMII module results in an outstanding performance when in interface with RMII and SMII DUTs. Wire-rate traffic generation and analysis, IP checksum error identification, a wide range of frame size, and comprehensive ARP analysis are a few of the promising features of the Spirent SmartBits LAN-3150A module. The Spirent SmartBits LAN-3150A Ethernet Module is supplied in a lightweight and compact structure weighing only 3 lbs. and having 14 × 12 × 4 inches dimensions.
