Spirent SmartBits LAN-3306A TeraMetrics XD Module

The SmartBits LAN-3306A is a powerful Ethernet Module. The developer of the SmartBits LAN-3306A module is Spirent Communications. The LAN-3306A module belongs to the class of TeraMetrics Modules offered by Spirent Communications. The brightest feature of the LAN-3306A Ethernet TeraMetrics XD Module is the provision of dual media Ethernet ports. Either GigE fiber connection or traditional Ethernet 10 Mbps, 100 Mbps, and 1000 Mbps connections can be made from the ports of the LAN-3306A dual media module. Possessing 4 dual media ports per module, the Spirent LAN-3306A module is listed under the highest port density modules class of the Spirent SmartBits products.

The LAN-3306A Ethernet TeraMetrics Module is designed for full-scale examination and testing of fully loaded network systems. Although the SmartBits LAN-3306A module is basically dedicated to the Layer 2 and Layer 3 network devices, Layer 4 to Layer 7 devices can also be tested with the LAN-3306A module: thanks to Avalanche SmartBits Application by Spirent Communications. A user-defined traffic generation with customized frames ranging from all zeros or ones to random IPs is made possible with the SmartBits LAN-3306A module. The Spirent SmartBits LAN-3306A module is an ideal choice when testing Ethernet to Ethernet, Ethernet to ATM, or Ethernet to POS networks is required.

The SmartBits LAN-3306A Ethernet XD Module can be used with the Spirent SmartBits SMB-600, SMB-600B, SMB-6000B, or SMB-6000C Performance Analyzers. The SmartBits LAN-3306A Ethernet Module presents accurate testing results of layer 2 to layer 7 DUTs in graphical as well as in the form of tables for a convenient interpretation by the users. With the capability of simulating extra large-scale network systems, the SmartBits LAN-3306A module supports a frame size of 40 to 16,384 bytes in transmission mode.
