Tektronix DPO5034 Advanced Phosphor Oscilloscope

With the Tektronix DPO5034 Advanced Phosphor Oscilloscope, you will be able to analyze up to 20 analog and digital signals with an absolute instrument to rapidly find and diagnose issues in complex designs. Its 350MHz bandwidth capacity and 5 GS/s sample rate guarantee that you will have the execution you need to check fast-changing signal details. To catch long windows for signal activity while maintaining fine timing resolution, the DPO5034 offers a profound record length of upon 12. 5M focuses standard on all channels and a nonobligatory record length of up to 250M focuses on two channels. With Wave Inspector® controls to fast waveform navigation, and more than 10 nonobligatory software and analysis packages for common technologies and in-depth analysis tasks, the DPO5034 gives those feature-rich devices you need to simplify your complex design.

 The Tektronix DPO5034 offers a strong set of highlights that should speed each phase of debugging; from finding an issue and catching it, to checking your waveform record for the event and analyzing its qualities and your device's functionality. The DPO5034's advanced phosphor innovation provides you with quick insight into the real operation for your gadget. Its quick waveform catch rate — superior to 250,000 wfm/s — provides you a high probability of rapidly seeing the infrequent issues for advanced systems, like runt pulses, glitches, and timing issues.

This model has 350 mhz of data transfer capacity, 5 GS/s of Real Time Sample rate on its four channels, 12. 5M record length and a FastFrame segmented memory acquisition mode for >310,000 Frames for every second capture rate.
