Tektronix TDS2024B Digital Storage Oscilloscope

The TDS2024B Digital Storage Oscilloscope created by Tektronix is ideal for applications such as the following: education and training, manufacturing test and quality control, service and repair, and design and debug. This model has 12 automatic measurements, removeable data storage through the USB port on the front panel, Fast Fourier Transform (FFT), and the ability to print directly to any Pict-bridge compatible printers by utilizing the USB device port.

The Tektronix TDS2024B has a ¼ VGA LCD color display screen with an adjustable multilevel contrast, a bandwidth of 200 MHz, 4 channels, external trigger input, a sample rate of 2.0 GS/s on every channel, and a record length of 2.5K points. The TDS2024B Digital Storage Oscilloscope can be combined with the AFG3000 Series arbitrary function generator, thus providing the user with the abilities of a function generator and the performance of an arbitrary waveform generator. This pair will allow the user to precisely validate, confirm, and characterize designs competently and swiftly at an economical cost.

The TDS2024B Oscilloscope has multiple data transfer options, ensuring that moving and saving data is easier than ever. USB host and device ports can be utilized, along with connecting to a PC. The maximum USB flash drive size is 64 GB, with the ability to save the following data for every 8 MB: 96 or more reference waveforms, 4,000 front-panel setups, 128 or more screen images, and 12 or more Save All operations.

The Tektronix TDS2024B has a user manual available for download on the apexwaves.com website for more information on the model and its specifications.
