TDS3052B

Tektronix Digital Phosphor Oscilloscope

Application Modules & Accessories:


• TDS3FFT FFT Application Package - The FFT application package adds FFT analysis and measurement capability to your TDS3052B oscilloscope. Application packages can be installed by the user. Further information can be found in the TDS3052B programmer manual.
• TDS3TRG Advanced Triggering application package - The advanced triggering application package adds pulse-width, slew-rate, pattern, state, runt, and edge-delay triggering capability to your TDS3052B oscilloscope. Application packages can be installed by the user. Reference the user manual for the TDS3052B.
• TDS3AAM Advanced Analysis Module - Adds extended math capability, arbitrary math expressions, measurement statistics and additional automated measurements.
• TDS3LIM Limit Testing Module - Offers fast, accurate Go/No Go verification that tested circuits are operating within intended parameters. For use with the TDS3052B.
• TDS3TMT Telecommunications Mask Testing Module - Pass/Fail compliance of ITU-T G.703 and ANSI T1.102 standards, custom mask testing and more. This module is compatible with TDS3052B Tektronix scope.
• TDS3VID Extended Video Editing Module - Adds Video QuickMenu, autoset, holdoff, line count trigger, video picture mode, vectorscope mode, HDTV format triggering graticules, and more. Refer to the TDS3052B user manual for more information on options and modules.
• TDS3SDI 601 Serial/Digital Video Module - Identify and analyze ITU-R BT.601 video signals, video picture mode with bright line select, vectorscope mode, etc.
• TDS3VM VGA/RS-232 Communication Module - This communication module adds VGA and RS-232 ports to your TDS3052B oscilloscope. You can attach a printer to the RS-232 port or use it for remote programmability. You can attach a monitor to the VGA port to enhance viewing the screen from a distance. Communication modules can be installed by the user and include the TDS3052B TDS3000-Series oscilloscope Programmer Manual.
• TDS3GV Module – Adds VGA, GPIB, and RS-232 interfaces, as well as the TDSPCS1 OpenChoice PC Communication software to the oscilloscope.
• TDS3EM Ethernet Communication Module - This communication module adds Ethernet 10baseT and RS-232 ports to your TDS3052B oscilloscope. You can attach the oscilloscope to an Ethernet network for remote printing. Communication modules can be installed by the user and include the TDS3000-Series Programmer Manual TDS3052B.
• TDS3CHG External Battery Charger - The battery charger recharges the oscilloscope battery pack in approximately 3 hours. For use in the TDS3052B digital phosphor oscilloscope.
• TDS3BAT Rechargeable Battery Pack - An extra rechargeable battery pack provides a high-capacity spare battery for extended portable operation. For use in the TDS3052B digital phosphor oscilloscope.
• TDS3PRT Plug-In Printer – With this portable printer, the user can easily print documents anywhere the TDS3052B will operate.

How-to Troubleshoot the TDS3052B Tektronix TDS3000B Oscilloscope

General Troubleshooting Tips

• Verify that your factory defaults were in fact recalled before configuring your scope or taking any measurements.
• Double check the circuit configuration. An incorrect connection or missing wire could alter your results.

Function Check procedure for Tektronix Oscilloscope

1. Connect your oscilloscope power cable
2. Power on your oscilloscope. Confirm that self tests have passed.
3. Connect your oscilloscope probe to channel 1. Connect the probe tip & reference lead to PROBE COMP connectors.
4. Press the AUTOSET button. You should see a square wave in the display (approx. 5V at 1kHz).

Troubleshoot: RS-232 Communications Port

1. Verify the correct cable and adapters are in use
2. Verify that cables are connected to the correct ports
3. Reset the RS-232 parameters to Defaults, then set the Baud Rate to match the computer or hard copy device.
4. Enable the debug window to view the RS-232 status, data transmitted, data transceived, and errors.

Troubleshoot: No signals onscreen (after scaling & offsetting)

• Double check for loose wiring or connections from the probe alligator clips / grabber clips.
• Verify your black leads from the probes are grounded.
• If earth ground is present, verify black leads of the probes and earth ground are at the same potential.

 Troubleshoot: Unexpected signal onscreen

• Double check the timescale, a small piece of a larger waveform might be displayed.
• Double check that probe clips are connected to the correct circuit node.

 If your problem persists

• Recall factory defaults once more and try again
• Contact Tech Support for further assistance
