BK Precision XLN3640 DC Power Supply

The BK Precision XLN3640 is a 1560 watt, High Power, Programmable DC Power Supply featured with USB and RS485 interfaces. This model comes with easy to configure master/slave modes for connection of up to 4 units in either series or parallel arrangements. This power supply offers a controllable current and voltage slew rate and allows "soft starting" of loads. The BK Precision XLN3640 is an ideal solution for different applications requiring reliable, high power, such as product QC, product design, ATE systems integration, burn-in testing, electro-plating, and production.

The BK Precision XLN3640 offers < 50 ms fast average command processing times. This model is a small 1 U high and 19-inch wide power supply that is created to meet the requirements of both benchtop users and system integrators. With this model, the benchtop users can take advantage of the incorporated meters provided for voltage and current values. These meters relay settings and output values simultaneously. This model comes with an instinctive user interface, which includes a rotary knob and full keypad.

The BK Precision XLN3640 offers a fixed auxiliary output of 5 V/1 A, which is fully compatible with LabVIEW. The user can have as many as 30 power supplies controlled using only one synchronized personal computer through the powerful RS-485 interface. This model is an easily programmable one, since it comes with an external programmable interface. As far as its protection features are concerned, the BK Precision XLN3640 offers 2--38V OVP adjustment range at an outstanding 200 mV OVP accuracy.
