Anritsu 69017B Synthesized Signal Generator

The Anritsu 69017B Synthesized Signal Generator has a Frequency Range between 10 MHz to 8.40 GHz, an Output Power of +13 dBm to -15 dBm (-20 dbm typical) with an attenuator of -120 dBm, and 100 MHz of Frequency Resolution.

This Synthesized Signal Generator model 69017B has an RF Signal Filtering, where the RF motion from the modulator is steered by means of PIN changes to the exchanged low-pass channels. Stick switch drive current is received from the A9 PIN Control PCB. A coupler in the exchanged channel way gives the RF signal to the down converter. At whatever point an instrument is producing RF signals of 40 GHz, a RF signal is coupled out by means of J4 to the source quadruple module. The exchanged low-pass channels give dismissal of the harmonics that are produced by the YIG-tuned oscillator. After being routed through the suitable way, the RF motion from 10 to 8.4 GHz is multiplexed by the PIN switches and goes through a low-pass channel of 20 GHz to the exchanged signal of the output connector of the channel set J2. The RF motion from 0.01 to 2 GHz (0.01 to 2.2 GHz for all units with choice 21A), from the down converter, is received at connector J1 and multiplexed through a similar way to the exchanged channel yield J2.

If you want to learn more about this unit and its specifications and options, you can read its users’ manual, available on the ApexWaves.com website.
