Anritsu 69037B Synthesized Signal Generator

The Anritsu 69037B Synthesized Signal Generator has a Frequency Range between 2.0 to 20.0 GHz, an Output Power of +13.0 dBm, an Output Power with Step Attenuator of +11.0 dBm, and an Output Power with Electronic Step Attenuator of +3.0 dBm.

To confirm that the 69037B time base is inside its aging specification, you should take into account that the instrument gets its recurrence precision from an inside 100 MHz crystal oscillator standard. With Option 16 introduced, recurrence exactness is received from an inside high-dependability 10 MHz crystal oscillator. An intrinsic characteristic for crystal oscillators is the impact of crystal aging inside the initial couple of days to a long time of operation. Normally, the crystal aging oscillator's recurrence increments marginally at first, and then settles to a generally steady pace for whatever is left of its life. Try not to confuse crystal aging with other recurrence dangers, such as noise and temperature. The inner time base of the instrument may not accomplish its predefined crystal aging before the predetermined warm-up time of 7 to 30 days has elapsed; in this manner, this execution test is discretionary. For most noteworthy total recurrence exactness, you should permit the 69037B to warm up until the point when its RF output recurrence has balanced out (typically 7 to 30 days). Once balanced out, the adjustment in reference oscillator recurrence ought to stay inside the aging rate. If the time base broiler isn't permitted to cool, the instrument orientation with respect to the earth's magnetic field is maintained, and the instrument does not maintain any mechanical shock.
