Tektronix AFG3251 Arbitrary/Function Generator

The Tektronix AFG3251 is a 1-Channel, 240 MHz Arbitrary/Function Generator. This model offers 1 µHz to 240 MHz Sine Waves in standard operating modes and 1 µHz to 120 MHz in burst mode. The AFG3251 is a powerful instrument because it can provide the user an opportunity to work with 12 different, standard waveforms, including: Square, Sine, Pulse, Haversine, Lorentz, Decay, Noise, DC, etc. For all waveforms other than sine waves, this Arbitrary/Function Generator has a range of 1 µHz to 2.4 MHz. With this model, the user can input a frequency setting value precisely since it comes with 1 μHz or 12 digits frequency setting resolution and 2 ms effective frequency switching speed.

The Tektronix AFG3251 comes equipped with various communication interfaces; thus, it can easily be controlled and calibrated remotely. This model comes in a benchtop configuration, with physical dimensions for height, width, and depth of 156.3, 329.6, and 168.0 mm respectively. The net weight of this model is 4.5 kg. The Tektronix AFG3251 requires 100 to 240 VAC to operate and consumes less than 120 W of power. After powering on, the instrument proceeds with a self-calibration cycle of <16 seconds. To provide the user with a brilliant waveform experience, this model incorporates a 5.6 in. color LCD.

The Tektronix AFG3251 is an ideal solution for those looking for a reliable instrument with a multi-language user interface. The user can have this instrument`s user interface and help language changed to their native language. Languages included are English, Chinese, Korean, Japanese, and several others.
